Flip Tanedo | USLHC | USA

View Blog | Read Bio

CERN mug summarizes Standard Model, but is off by a factor of 2

Last month had the unique pleasure of making my first trip to CERN (more on that in a later post). I made a point to stop by the CERN gift shop to pick up a snazzy mug to show off to my colleagues back in the US, and am now the proud owner of a new vessel for my tea:

My brand new "Standard Model Lagrangian" mug from CERN.

The equation above is the Standard Model Lagrangian, which you can think of as the origin of all of the Feynman rules that I keep writing about. Each term on the right-hand side of the above equation actually encodes several Feynman rules. Roughly speaking, terms with an F or a D contain gauge fields (photon, W, Z, gluon), terms with a ψ include fermions, and terms with a ϕ include the Higgs boson. Some representative diagrams coming from each of the terms are depicted below:

Representative Feynman rules coming from each term in the Lagrangian.

But alas, there’s a bit of a problem with the design. It appears that there’s an extra term which isn’t included in the usual parametrization of the Standard Model:

This term really shouldn't be here. It's not necessarily "wrong," but it is misleading and doesn't match what is written in textbooks. Technically, it is not `canonically normalized.'

I won’t go so far as to call this a mistake because technically it’s not wrong, but I suspect that whoever designed the mug didn’t mean to write this term. Let me put it this way: if I had written the above expression, my adviser would pretend he didn’t know me. The “h.c.” means Hermitian conjugate, which is a generalization of the complex conjugate of a complex number. In terms of Feynman diagrams, this “+h.c.” term means “the same diagram with antiparticles.”

The problem is that the term above,

includes its Hermitian conjugate. In physics-speak, we say that the kinetic term is self-conjugate (or Hermitian, or self-adjoint). This just means that there is no additional “+h.c.” necessary. In fact, including the “+h.c.” means that you are writing the same term twice and the equation is no longer “canonically normalized.” This just means that you ought to rescale some of your variables.

I was mulling over this not-quite-correct term on my mug while looking over photos from CERN when I discovered the same ‘error’ in a chalkboard display in the “Universe of Particles” exhibit:

Display at the "Universe of Particles" exhibit in The Globe of Science and Innovation at CERN.

The “+h.c.” on the top right is the same ‘error’ as printed on the CERN mug. I wonder who wrote this?

To be clear: this expression does summarize the basic structure of the Standard Model in the sense that it does give all of the correct Feynman rules. However, the extra “+h.c.” introduces a factor of two that needs to be accounted for by weird conventions elsewhere (that would not match any of the usual literature or textbooks).

Nit picky remarks for experts. It is worth noting that the above expression does get one thing absolutely right: it writes everything in terms of Weyl (two-component) fermions, as appropriate for a chiral theory like the Standard Model. One can see that these as Weyl fermions because the Yukawa term contains two un-barred fermions (the “+h.c.” gives two barred fermions). Note that even for Weyl fermions, one shouldn’t have a “+h.c.” on the kinetic term. In fact, I would typically write the D-slash with a bar since it contains a barred Pauli matrix, but this is a matter of personal convention. The “+h.c.” is not “personal convention” since it means the kinetic term is not canonically normalized.

Anyone who has done tedious physics calculations is familiar with the frequent agony of being off by a factor of 2. Now when people make remarks about this ‘error’ on my mug, I’m quick to tell them that the factor of 2 mistake just makes it more authentic.

  • At least, let’s hope that CERN has correctly measured the circumference 27 kilometers and it’s not just 13.5+13.5 where the right circumference is just 13.5 kilometers. 😉

    If it is supposed to be the Standard Model, the F-mu-nu-F-mu-nu should also be a trace, or summed over adjoint indices, right?

  • Hi Lubos. Good point about the trace. I think I’m willing to take this as assumed since none of the other gauge indices are written explicitly. 🙂

  • gregor

    Maybe you should contact John Ellis about this:



  • Innocent Bystander

    What about the Yukawa term? Unless we are asuming all fermions to be Majorana, how does that term have two psis and no pisi-bars?

  • Hi Innocent Bystander, written in a Weyl basis, the Yukawa term connects two left-chiral particles or two right-chiral particles. You can see this just from the spinor structure: either there are two undotted indices or two dotted indices. Alternately, you can write out the usual Yukawa term with Dirac spinors and then write the Dirac spinor in terms of Weyl spinors.

    I think the main confusion is that the Yukawa term has, for example, a left-chiral particle and a the anti-partner of a right-chiral particle. The latter field is a left-chiral field, so that you end up with two unbarred fields. Similarly, the “+h.c.” contains two barred fields.

    Great question.


  • @ Gregor: *LoL* The conspiracy goes all the way to the top!


  • Shea

    Perhaps the “+h.c.” is someone’s initials. You said that it doesn’t make the equation technically wrong. perhaps that was just their idea of a joke. They noticed their initials were short for Hermitian conjugate and added it to the end as an inside joke knowing very few people would actually get it and understand it. Look around for anybody with those initials who works there and would understand it.

  • GJKD

    I’ve heard from a quite trustworthy source that it is John Ellis’ handwriting on the mug. Perhaps you gotta check this beef with him 😉

  • Wicked

    Shea is on to something.

    +h.c. I would fathom means “plus hot coffee” as well as an in joke of being off by a factor of 2

  • Doug

    Nice try Wicked, but why does Globe of Science exhibit have the same “misstep”?

  • not an elephant

    “whoever”, not “whomever.

  • Good catch, not-an-elephant! Post corrected, thanks.

  • Matt

    When may we expect this mug to be discussed on “The Big Bang Theory?”

  • If physics used Tau instead of Pi, perhaps all those awful “off by a factor of 2” errors would go away

  • Hi Matson. Ah, tau day. Alas, while historically it may have been nicer to have used tau instead of pi, humans have more or less adapted to this convention particularly well. Unfortunately, the factors of 2 which are puzzling aren’t typically from pi versus 2*pi, but rather they often come from more subtle things like the quantum statistics of identical particles. -F

  • jason

    you’re all so silly and confused – the hc stands for “hot coffee”. after all, it’s a mug. 🙂

  • Nitin

    It seems you’re not the only one who’s noticed that recently. M Shifman posted a similar remark on his Facebook wall, with picture (hopefully his are publicly visible): https://www.facebook.com/photo.php?fbid=244828688867538&set=a.101417873208621.3533.100000212256542&type=1&ref=nf

  • How about dark matter, doesn’t that probably involve violating the Standard Model? So most of the universe doesn’t follow those rules anyway …

  • Hayden

    I love reading articles like this.. because for a layman like me every second word could be invented and the whole thing sounds like such an abstraction that its actually hard to tell if this is real or not.

  • kb

    Is there any way to get a mug sent to North America? I googled and couldn’t find a Cern gift shop website but apparently that’s because it is a not for profit so there are some rules around it. Any ideas?

  • Hi kb, unfortunately I’m also at a loss for this. It seems like ATLAS has an online gift shop, but they don’t seem to have the mug available. Maybe you could try contacting them to see if they can put you in contact with the main gift shop?

  • kb

    Yeah, I saw the ATLAS site too, but good idea to contact them, thanks!

  • AlexandreFaure

    Thanks for this very interesting post Flip !

  • Dirk Bold

    What the heck are y’all talkin’ about.

    Tau, Tau,


  • Sheldon

    Never, the writers of the show know diddly squat about physics

  • The writers may not know much physics, but there’s a physics professor at UCLA who consults on their whiteboard equations and (to the best of my recollection) these are all correct and have (in the past) made their way into the show. 🙂

  • So the mug is defective. Can I get 50% off when I buy it then?

  • Taeuk Nam

    Is the h.c. In the 3rd line required?

  • Patrick Hurley

    You can get Standard Model mugs and t-shirts from Zazzel Inc.

  • J

    I purchased the same mug during the Open Days event along with the matching tote. I am planning on stealing your “more authentic” quip! lol Thanks.
    We too noticed this error, and while discussing the anomaly a non-physicist friend pointed out that it looks more like thc (tetrahydrocannabinol), not + h.c.
    Perhaps this is the real reason for the oversight! lol
    Thanks again for the post.

  • Ephemeron

    Ah but dark matter is the force of gravity where the mass (particle) on a string never enters the location of spacetime in which the gravity is manifest. String piercing the brane but particle not passing it. 😉

  • Mathgeek

    Well, it. is quite interesting that this question seems to pop up everywhere. I spent a couple of days at CERN this summer, to get updated in Quantum fields. We spent quite some time discussing the S.M. and the Lagrangian of the S.M. and we worked hard to find the meaning of this extra term that pops up on the souvenirs. At CERN there seems to be a consensus that it stands for hot coffee (you always need some when working on the Lagrangian). It might have started as a misspelling but they have kept it. as a joke towards all those that have no clue of what the equation means.

  • QuantumGeek

    Which equation is correct then?

    I swear I have seen multiple versions of it.
    At https://www.youtube.com/watch?v=mrft3T6ffKw at 3:33 it shows the equation and it starts with the uv being in the superscript not subscript and there’s also an i there.

    Is the equation in the YouTube video wrong that is wrong aside from just the extra +h.c.?

    Also it’s infuriating that I can’t seem to find anywhere, anywhere on the internet that spells out what each variable and symbol is in any of the versions of the equation I’ve come across.

  • Tony Mendible

    Would any of you please tell me where to buy one of this mug? I went to CERN Opendays last september I saw the mug but at last moment couldn´t buy the mug…GRRRR!
    Sorry my request isn´t deeper as precedents. 😉

  • MissBumblebee

    I was told by a physicist in CERN, that the addidional h.c. means “hot coffee”…

  • Thanks so much Flip. I was going crazy thinking I was wrong that the additional h.c. shouldn’t be there!

  • Cast

    I just wanted to inform you that they have corrected the mug.

    🙂 N’Joy your coffee (or whatever)

  • BoldEagle

    Yes, the h.c. is canonically, hot coffee. At least between 4:00 am and noon gmt. Otherwise, little reliable physics gets done for half the day. That explains the 2 factor.
    PS: Nice mug!

  • Pythagore

    In fact, you got two mugs before renormalisation for the price of one.

  • Pythagore

    Not true, I just got this mug as a gift from my two daughters and the extra term is there. I am glad to be the proud owner of the authentic mug.

  • Cast

    Obviously they mixed the correct and the wrong ones.
    I am so jealous. I want to have a wrong one too. 🙂

  • Pythagore

    After checking, they may not have mixed anything. I received the mug as a gift from my daughters and they told me they ordered the mug more than a year ago. Because the CERN’s Shop doesn’t ship outside Europe, they had to make arrangements with a third party in London to ship the gift in America.

    For an unknown reason, the third party just shipped the order last week. So, I believe they may have received the mug more than a year ago.

  • Don’t worry… the standard model is not correct so no matter what cup you have, you have a wrong one!

  • Cast

    I have never seen it like this! Your Post made my day sir.

  • Frank_Truth

    If the mug is defective, doesn’t that make it worth more like double-struck coins, and coins minted with other defects?

  • ummm… No! The standard model is not correct so all mugs are defective.
